    MECHANICAL PROPERTIES

    Pitch: 0.50mm(min)

    Working Travel: 0.43mm

    Contact Force(0.43mm): 39.7gf or 26.5gf

    Full Length: 2.95mm

    Compressed Length: 2.52mm

    Operating Temperature: -55°C to +180°C

    Mechanical Life:  500,000 cycles

    ELECTRICAL PROPERTIES

    Contact Resistance: <35 mΩ

    Current Rating (free air): 2.9amp

    Self Inductance: 0.88 nH

    Capacitance: 0.097 pF

    Bandwidth@-1dB: 15.7 GHz

    MATERIALS

    Stamped Contact: BeCu, Au Plate

    Spring: SS, Au Plate
